Equipment

Accelerating the renewal of high-end equipment is the foundation for transformation and upgrading as well as improving quality and efficiency. People are the theme of quality, but they are also the most unstable factor. A good product must first be guaranteed by good processes, equipment and tooling.
The company has installed an intelligent equipment management platform. Currently, over 600 sets of handling and welding robots have been installed, with a network connection rate of 95%. More than 100 welding assembly lines have been put into use, and the full assembly line automation rate of products has reached 85%.

• Fully automatic double-girder main beam inner seam robot welding workstation



  This workstation is mainly used to achieve the automatic welding of the inner seams of the double-girder main beams. After the manual loading is basically centered in the horizontal and vertical directions, the workpiece is flipped ±90° through the L-arm hydraulic flipper, and the robot automatically locates and welds. It significantly improves the quality of the welds and enhances the welding efficiency of crane structural components, especially demonstrating a considerable advantage in the welding of inner seams. It is also another measure taken by Henan Mine to care for its employees and improve quality and efficiency.

• Single-beam main beam inner seam robot welding workstation



  The company has collaborated with the Beijing Crane and Transport Machinery Design and Research Institute and hired German crane experts to complete the "Flexible Production Line for Single-girder Cranes". As a result, the main girder production line of cranes can produce finished products every hour, reducing production time by 40% and shortening the customer delivery cycle by 50%. Since 2016, we have gradually introduced robot welding assembly lines, which can complete the welding of various weld seams of the company's single-beam standard products.

•
  Automatic loading and unloading robot
•
  LD wheel rolling assembly line in the steel casting workshop
•
  Intelligent robot painting production lines, automatic spray painting lines
•
  Intelligent cable production line -1+6+12+18 cable forming machine
•
  Overall quenching and tempering automated production line
•
  Car-type annealing furnace
•
  CNC floor boring and milling machine
•
  CNC fixed-beam gantry mobile boring and milling machining center
•
  Finishing department
•
  Testing Center - Three-coordinate Measuring Instrument
•
  Multi-functional carburizing furnace
•
  End beam welding robot
•
  Moving beam gantry mobile boring and milling machining center
•
  In the process of moving the fixed-beam gantry
•
  Single-beam main beam flexible production line, flipping platform
•
  Single-beam stiffening plate assembly and welding workstation
•
  The intelligent automated production unit for gear sheets is a six-axis articulated robot
•
  Intelligent assembly line for wheel forging and rolling composite process
•
  Ultra-high power fiber laser cutting machine
•
  U-shaped groove one-time forming production line
•
  300LD intelligent automated production unit for wheel axles
